Medical Gas Digital Alarm Panels

alarm panels

MedicalGas Digital Alarm Panelsis designed to continuously monitor the status ofsource equipment and pressure(vacuum)of medical gas lines ,has highly accuratelyand reliably,the system is made up of display module,sensor module,power moduleand the annunciator panel .

Onthe display module ,the actual line pressure is indicatored ,easy to readdigital display . when the line pressure
or vacuum exceeds the high or lowsetpoint, an alarm will be sound and an LED trend indicator on the displaymodule indicators the status of the pipeline .

theLED bar consists of the following colors: green,yellow,and red. The greenrepresents normal pressure, the yellow indicates a condition trending away fromnormal and the red indicates an alarm condition. in addition to the
trendindicator there is also an audible alarm, which sounds whenever an alarmcondition is
present .otherwise ,the alarm is connected to the master alarmor a building management system.
At the same time, the alarm monitors 1-6gases sources.
The alarm only use for monitor the medical gas system ,not usefor any other purpose.

Specification

Medical Gas Digital Alarm Panels

a.1-8 gases can be choose (O2, VAC, N2, N2O, AIR, SURGICALAIR,CO2,EVAC)

b.110V 60HZ or 220V 50HZ can be choose

c.Power:10W

d.Current:0.1A

e.Sound degree: 70db±1 db

f.Work mode :continuous

Alarm PanelsInternal Structure
